GMC Hydraulic Rotary Draw Bender DB-60A

by GMC Machine Tools
Save 14%
$7,350.00
$6,350.00
Notify me when back in stock
Free Shipping to the Lower 48!
Authorized GMC Machine Tools Dealer
Manufacturer's Warranty on All GMC Products
Proudly Tradesman Owned and Operated
No State Sales Tax Outside of PA. It's On Us!

GMC DB-60A, max 2” tube / 1-1/2” pipe,  1-1/2HP, 220V,1 phase

  • Taiwan Machine
  • ISO 9001 certified
  • NC-control for bending angle adjustment
  • LED degree indicator with automatic stop programming, to get as true reading of bending degree.
  • Up to 50 jobs memory; each job program contains 9 steps
  • Counter roller holder comes standard with quick adjustment
  • This easy to use hydraulic tube draw bender has an incredible capacity of 2” tube with .12” wall thickness and 1-1/2” schedule# 40 pipe
  • 1-1/2 HP motor, 220VAC, Single Phase
  • Quick tooling changes
  • With deluxe stand
  • One year warranty for parts
Specifications and Manual
Specification Value
Capacity
Minimum CLR 1/2"
Minimum OD 1/4"
Solid Rod, Mild Steel 1”
Round Tube, Mild Steel (Wall Thickness) 2” (.125”)
Round Pipe, Mild Steel, Schedule 40 1-1/2”
Round Tube, SS Steel (Wall Thickness) 1-1/2” (.125”)
Round Pipe, SS Steel, Schedule 40 1-1/4”
Aluminum Round Tube (Wall Thickness) 2” (3/16”)
Maximum Centerline Radius
Maximum Centerline Radius 6-1/2” CRL
LED Programming
LED Programming 50 job memory
Motor
Main Motor 1.5HP, 220V, 1 Phase
Weight & Dimensions
Weight 327 LBS
Machine Dimensions (LxWxH) 27” x 9” x 51”
Shipping Dimensions (LxWxH) 62” x 27” x 43”

GMC DB-60A, max 2” tube / 1-1/2” pipe,  1-1/2HP, 220V,1 phase
  • Taiwan Machine
  • ISO 9001 certified
  • NC-control for bending angle adjustment
  • LED degree indicator with automatic stop programming, to get as true reading of bending degree.
  • Up to 50 jobs memory; each job program contains 9 steps
  • Counter roller holder comes standard with quick adjustment
  • This easy to use hydraulic tube draw bender has an incredible capacity of 2” tube with .12” wall thickness and 1-1/2” schedule# 40 pipe
  • 1-1/2 HP motor, 220VAC, Single Phase
  • Quick tooling changes
  • With deluxe stand
  • One year warranty for parts
Specification Value
Capacity
Minimum CLR 1/2"
Minimum OD 1/4"
Solid Rod, Mild Steel 1”
Round Tube, Mild Steel (Wall Thickness) 2” (.125”)
Round Pipe, Mild Steel, Schedule 40 1-1/2”
Round Tube, SS Steel (Wall Thickness) 1-1/2” (.125”)
Round Pipe, SS Steel, Schedule 40 1-1/4”
Aluminum Round Tube (Wall Thickness) 2” (3/16”)
Maximum Centerline Radius
Maximum Centerline Radius 6-1/2” CRL
LED Programming
LED Programming 50 job memory
Motor
Main Motor 1.5HP, 220V, 1 Phase
Weight & Dimensions
Weight 327 LBS
Machine Dimensions (LxWxH) 27” x 9” x 51”
Shipping Dimensions (LxWxH) 62” x 27” x 43”
