Sharp Industries 30" x 160" Heavy Duty Gap Bed Lathe 30160-V
There is a 6% surcharge on all Sharp products due to tariffs.
Feel free to call in to ensure product availability and lead times.
$98,400.00
Free Shipping to the Lower 48!
Authorized Sharp Industries Dealer
Manufacturer's Warranty on All Sharp Products
Proudly Tradesman Owned and Operated
No State Sales Tax Outside of PA. It's On Us!
The model heavy duty lathe has 4.125” spindle bore, D1-11 Camlock spindle head,19” wide bed and wide range of threading capacity. Coarse thread reaches ¼ “ TPI.
- D1-11 camlock spindle
- Clutch type geared head
- 4.125″ spindle bore
- 15 hp motor
- 18 speeds (10-1,200 rpm)
- Wide thread range (1/4 tpi – 84 tpi)
- 19″ wide bed
- Multiple leads thread indicator
Specifications and Manual
| Specification | 30160V |
|---|---|
| Capacity | |
| Swing Over Bed | 30″ (762 mm) |
| Swing Over Cross Slide | 14.75″ (374.6 mm) |
| Swing Over Gap | 39″ (990.6 mm) |
| Distance Between Centers | 160″ (4064 mm) |
| Headstock | |
| Spindle Speed | 10–1,200 rpm |
| No. of Speeds | 18 |
| Spindle Nose | D1‑11 camlock |
| Spindle Bore | 4.125″ (104.6 mm) |
| Threads & Feeds | |
| Threads, Number | 0.25–84″, 60 kinds (0.2–112 mm, 60 kinds) |
| Modular Threads | 0.05–28 mm, 55 kinds |
| Diametral Pitch | 1–240 DP, 55 kinds |
| Longitudinal Feeds | 0.0015–0.2″/rev (0.0381 mm/rev) |
| Cross Feeds | 0.0006–0.16″/rev (0.0152–4.06 mm/rev) |
| Leadscrew Pitch | 1.5″/2 TPI |
| Carriage | |
| Cross Slide Travel | 14.75″ (374.6 mm) |
| Compound Travel | 9″ (228.6 mm) |
| Compound Width | 30.25″ (768.3 mm) |
| Bed & Tailstock | |
| Bed Width | 19″ (482.6 mm) |
| Quill Diameter | 3.12″ (79.2 mm) |
| Quill Travel | 7.5″ (190.5 mm) |
| Quill Center Taper | MT #5 |
| General | |
| Spindle Motor | 15 HP (11.18 kW) |
| Voltage | 220/440/575 V |
| Phase | 3 phase |
| Power Cons. (220 V) | 15 kVA/40 A |
| Power Cons. (440 V) | 15 kVA/20 A |
| Power Cons. (575 V) | 15 kVA/15 A |
| Approx. Weight | 8200 lbs (3719 kg) |
Standard Equipment
- Steady rest with roller jaws
- Face plate 20″
- Coolant system
- Longitudinal carriage stop
- Halogen work light
- Tailstock with 2 speeds on quill
- Wired 220V or 440V
Optional Add-Ons
Call for Price
- Taper attachment
- Roller jaw set (3 pcs) for steady rest
- 3-jaw chuck 12″
- 4-jaw chuck 16”
- Follow rest
- Quick change tool holder
- Live center – (dual bearing) MT #5
- Live center – MT #5
- Micrometer carriage stop
- Steady rest, 8-3/4′ – 13″, 11″ – 17″ ,14″ – 21″
- 20 HP motor in lieu of 15 HP motor
- Rear splash guard (80″ / 120″ / 160″ length) • CSA or UL electrical parts and wiring
- Chuck guard with limit switch
- Tool post guard
- Spindle rear end cover
- Lead screw cover
